Ion Torrent 7467 Personal Genome PGM System

Product Information

The Ion Torrent 7467 Personal Genome PGM System combines semiconductor sequencing technology with natural biochemistry, translating chemical information into digital data. It democratizes sequencing, making it accessible to various labs and leverages improvements in the semiconductor industry. This system employs direct, real-time sequencing detection, yielding results in around 37 hours. It's ideal for sequencing small genomes and targeted panels, offering an affordable solution with a small benchtop footprint. The sequencing technology exploits a well-characterized biochemical process by directly detecting nucleotide incorporation without the use of light. Moreover, this system uses natural nucleotides, eliminating the need for expensive modified bases and providing accurate results quickly.

• Fast and efficient direct sequencing system
• Compact design with a small benchtop footprint
• Uses natural nucleotide sequencing chemistry
• Employs direct, real-time sequencing detection

• CPU: Dual 6-core 2.66 GHz CPUs
• Capacity: 1 chip per run
• Chip Compatibility: Ion 314 Chip v2 BC, Ion 316 Chip v2 BC, Ion 318 Chip v2 BC
• Current Limit: 6.7 A (max)
• Data Output: BAM Files, FASTQ Files, SFF Files, VCF Files
• Display Interface: Touchscreen User Interface
• External Computer: Torrent Server
• For Use With (Equipment): Ion PGM System
• Frequency: 50-60 Hz
• High Throughput Compatibility: High Throughput-Compatible, Multiplexing
• Instrument Memory: 48 GB RAM, Eight 2 TB Hard drives in RAID 5
• Operating System: Ubuntu 10.04
• Output: Ion 314 Chip v2: Up to 100 Mb, Ion 316 Chip v2: Up to 1 Gb, Ion 318 Chip v2: Up to 2 Gb
• Product Line: Ion Torrent, Personal Genome Machine (PGM)
• Product Size: 1 instrument
• Read Length: 35400 bases (average: 200 bases)
• Reads/Run: Ion 314 Chip v2: 400-500 thousand, Ion 316 Chip v2: 2-3 million, Ion 318 Chip v2: 4-5.5 million
• Run Time: Ion 314 Chip v2: 2.3 to 3.7 hr, Ion 316 Chip v2: 3.0 to 4.9 hr, Ion 318 Chip v2: 4.4 to 7.3 hr
• Sequencing Scale: 3 Mb to 2 Gb
• Technique: Post-Light Ion Semiconductor Sequencing
• Throughput: Up to 2 Gb per run
• Voltage Limit: 100V (min) to 240V (max)

Metric: 65 kg
Imperial: 143.3 lbs

Metric: 70 cm x 65 cm x 65 cm
Imperial: 27.56 in x 25.59 in x 25.59 in
